How to Use LED: Two Pin (yello) - Long Pins: Examples, Pinouts, and Specs

Image of LED: Two Pin (yello) - Long Pins
Cirkit Designer LogoDesign with LED: Two Pin (yello) - Long Pins in Cirkit Designer

Introduction

A yellow light-emitting diode (LED) is a semiconductor device that emits yellow light when an electric current flows through it. This specific LED features two long pins, making it easy to integrate into breadboards and circuit boards. It is commonly used for visual indicators, such as power or status signals, in electronic circuits. Its bright yellow light is ideal for applications requiring clear visibility.

Explore Projects Built with LED: Two Pin (yello) - Long Pins

Use Cirkit Designer to design, explore, and prototype these projects online. Some projects support real-time simulation. Click "Open Project" to start designing instantly!
LED Array with Inductive Power Transfer
Image of Wind Mill: A project utilizing LED: Two Pin (yello) - Long Pins in a practical application
The circuit consists of multiple red two-pin LEDs connected in parallel, with all cathodes tied together and all anodes tied together. A copper coil is also connected in parallel with the LEDs. There is no control circuitry or power regulation components indicated, and no embedded code provided, suggesting this is a simple illumination circuit possibly intended for inductive power transfer given the presence of the copper coil.
Cirkit Designer LogoOpen Project in Cirkit Designer
Raspberry Pi 4B Controlled Multi-Color LED Indicator
Image of Task1-osama: A project utilizing LED: Two Pin (yello) - Long Pins in a practical application
This circuit consists of three LEDs (yellow, green, and red) each with a corresponding 220 Ohm resistor in series. The anodes of the LEDs are connected to their respective resistors, while the cathodes are likely intended to be driven by a Raspberry Pi 4B, as the resistors' other ends are connected to the Pi's 3.3V and GND pins. Without specific code, the functionality of the Raspberry Pi in this circuit cannot be determined, but it is likely used to control the LEDs.
Cirkit Designer LogoOpen Project in Cirkit Designer
Simple LED Circuit with Current-Limiting Resistors
Image of 모스시: A project utilizing LED: Two Pin (yello) - Long Pins in a practical application
The circuit consists of two independent sections, each containing a red LED in series with a 220-ohm resistor. The purpose of this circuit is likely for simple indication, with the resistors serving to limit the current through the LEDs to prevent damage.
Cirkit Designer LogoOpen Project in Cirkit Designer
Raspberry Pi Controlled LED Array with Resistors
Image of 10led: A project utilizing LED: Two Pin (yello) - Long Pins in a practical application
This circuit consists of a Raspberry Pi 2B controlling eight red LEDs and two yellow LEDs through its GPIO pins. Each LED is connected in series with a 1000 Ohm resistor to ground, allowing the Raspberry Pi to individually control the illumination of each LED.
Cirkit Designer LogoOpen Project in Cirkit Designer

Explore Projects Built with LED: Two Pin (yello) - Long Pins

Use Cirkit Designer to design, explore, and prototype these projects online. Some projects support real-time simulation. Click "Open Project" to start designing instantly!
Image of Wind Mill: A project utilizing LED: Two Pin (yello) - Long Pins in a practical application
LED Array with Inductive Power Transfer
The circuit consists of multiple red two-pin LEDs connected in parallel, with all cathodes tied together and all anodes tied together. A copper coil is also connected in parallel with the LEDs. There is no control circuitry or power regulation components indicated, and no embedded code provided, suggesting this is a simple illumination circuit possibly intended for inductive power transfer given the presence of the copper coil.
Cirkit Designer LogoOpen Project in Cirkit Designer
Image of Task1-osama: A project utilizing LED: Two Pin (yello) - Long Pins in a practical application
Raspberry Pi 4B Controlled Multi-Color LED Indicator
This circuit consists of three LEDs (yellow, green, and red) each with a corresponding 220 Ohm resistor in series. The anodes of the LEDs are connected to their respective resistors, while the cathodes are likely intended to be driven by a Raspberry Pi 4B, as the resistors' other ends are connected to the Pi's 3.3V and GND pins. Without specific code, the functionality of the Raspberry Pi in this circuit cannot be determined, but it is likely used to control the LEDs.
Cirkit Designer LogoOpen Project in Cirkit Designer
Image of 모스시: A project utilizing LED: Two Pin (yello) - Long Pins in a practical application
Simple LED Circuit with Current-Limiting Resistors
The circuit consists of two independent sections, each containing a red LED in series with a 220-ohm resistor. The purpose of this circuit is likely for simple indication, with the resistors serving to limit the current through the LEDs to prevent damage.
Cirkit Designer LogoOpen Project in Cirkit Designer
Image of 10led: A project utilizing LED: Two Pin (yello) - Long Pins in a practical application
Raspberry Pi Controlled LED Array with Resistors
This circuit consists of a Raspberry Pi 2B controlling eight red LEDs and two yellow LEDs through its GPIO pins. Each LED is connected in series with a 1000 Ohm resistor to ground, allowing the Raspberry Pi to individually control the illumination of each LED.
Cirkit Designer LogoOpen Project in Cirkit Designer

Common Applications and Use Cases

  • Power or status indicators in electronic devices
  • Visual feedback in microcontroller projects
  • Decorative lighting in DIY projects
  • Signal indicators in control panels
  • Educational electronics kits and prototyping

Technical Specifications

Below are the key technical details for the yellow two-pin LED:

Parameter Value
Forward Voltage (Vf) 2.0V to 2.2V
Forward Current (If) 20mA (typical)
Maximum Current (Imax) 30mA
Wavelength 590nm (yellow light)
Viewing Angle 20° to 30°
Polarity Anode (+) and Cathode (-)
Pin Length Anode: Longer pin, Cathode: Shorter pin

Pin Configuration and Descriptions

Pin Name Description
Long Pin Anode (+) Connect to the positive terminal of the power source.
Short Pin Cathode (-) Connect to the negative terminal or ground (GND).

Usage Instructions

How to Use the LED in a Circuit

  1. Identify the Pins: The longer pin is the anode (+), and the shorter pin is the cathode (-).
  2. Connect a Resistor: Always use a current-limiting resistor in series with the LED to prevent damage. Calculate the resistor value using Ohm's Law: [ R = \frac{V_{supply} - V_f}{I_f} ]
    • (V_{supply}): Supply voltage
    • (V_f): Forward voltage of the LED (2.0V to 2.2V)
    • (I_f): Desired forward current (typically 20mA)
  3. Insert into Circuit: Place the LED and resistor in the circuit, ensuring correct polarity.
  4. Power the Circuit: Apply power to the circuit. The LED should emit a yellow light.

Example Circuit with Arduino UNO

Below is an example of how to connect the yellow LED to an Arduino UNO and control it using code:

Circuit Connections

  • Connect the anode (long pin) of the LED to a digital pin on the Arduino (e.g., pin 13) through a 220Ω resistor.
  • Connect the cathode (short pin) to the Arduino's GND.

Arduino Code

// This code blinks a yellow LED connected to pin 13 of the Arduino UNO.

// Define the pin where the LED is connected
const int ledPin = 13;

void setup() {
  // Set the LED pin as an output
  pinMode(ledPin, OUTPUT);
}

void loop() {
  // Turn the LED on
  digitalWrite(ledPin, HIGH);
  delay(1000); // Wait for 1 second

  // Turn the LED off
  digitalWrite(ledPin, LOW);
  delay(1000); // Wait for 1 second
}

Important Considerations and Best Practices

  • Use a Resistor: Never connect the LED directly to a power source without a resistor, as this can cause it to burn out.
  • Polarity Matters: Ensure the anode and cathode are connected correctly; reversing the polarity will prevent the LED from lighting up.
  • Avoid Overcurrent: Do not exceed the maximum forward current (30mA) to avoid damaging the LED.
  • Heat Management: In high-power applications, ensure proper heat dissipation to maintain LED longevity.

Troubleshooting and FAQs

Common Issues and Solutions

  1. LED Does Not Light Up

    • Cause: Incorrect polarity.
    • Solution: Verify that the anode is connected to the positive terminal and the cathode to ground.
    • Cause: Missing or incorrect resistor value.
    • Solution: Ensure a current-limiting resistor is used and properly calculated.
  2. LED is Dim

    • Cause: Insufficient current.
    • Solution: Check the resistor value and ensure the supply voltage is adequate.
  3. LED Burns Out Quickly

    • Cause: Excessive current.
    • Solution: Use a resistor with a higher resistance value to limit the current.
  4. LED Flickers

    • Cause: Unstable power supply or loose connections.
    • Solution: Check the power source and ensure all connections are secure.

FAQs

Q: Can I use this LED with a 3.3V or 5V power supply?
A: Yes, but you must use an appropriate resistor to limit the current. For a 5V supply, a 150Ω to 220Ω resistor is recommended. For a 3.3V supply, a 100Ω resistor is suitable.

Q: Can I connect multiple LEDs in series?
A: Yes, but ensure the total forward voltage of the LEDs does not exceed the supply voltage. Use a resistor to limit the current.

Q: How do I calculate the resistor value for multiple LEDs in parallel?
A: Each LED should have its own resistor. Calculate the resistor value for each LED individually based on the supply voltage and forward voltage.

Q: What happens if I reverse the polarity?
A: The LED will not light up, but it will not be damaged unless excessive reverse voltage is applied.

By following this documentation, you can effectively use the yellow two-pin LED in your electronic projects!
