The M10X2 is a metric screw with a diameter of 10 mm and a thread pitch of 2 mm. It is widely used in mechanical assemblies for securely fastening components together. Known for its robust design and precise threading, the M10X2 screw is a reliable choice for applications requiring strong and durable connections. Its standardized dimensions make it compatible with a variety of nuts, washers, and threaded holes.
