Image of lm8705
Cirkit Designer LogoDesign with lm8705 in Cirkit Designer

Introduction

The LM8705 is a high-performance, low-dropout (LDO) voltage regulator designed to provide a stable output voltage with low noise and high efficiency. It is ideal for applications requiring precise voltage regulation, such as battery-powered devices, portable electronics, and sensitive analog circuits. Its low dropout voltage and high power supply rejection ratio (PSRR) make it suitable for noise-sensitive environments.
