How to Use TL072: Examples, Pinouts, and Specs

Image of TL072
Cirkit Designer LogoDesign with TL072 in Cirkit Designer

Introduction

The TL072 is a low-noise JFET-input operational amplifier (op-amp) designed for high-speed and low-distortion performance. It features a dual op-amp configuration, making it ideal for applications requiring precision and low noise. The JFET inputs provide high input impedance, ensuring minimal loading on the signal source. This component is widely used in audio applications, signal processing, active filters, and instrumentation amplifiers.

Explore Projects Built with TL072

Use Cirkit Designer to design, explore, and prototype these projects online. Some projects support real-time simulation. Click "Open Project" to start designing instantly!
Battery-Powered Emergency Alert System with NUCLEO-F072RB, SIM800L, and GPS NEO 6M
Image of women safety: A project utilizing TL072 in a practical application
This circuit is an emergency alert system that uses a NUCLEO-F072RB microcontroller to send SMS alerts and make calls via a SIM800L GSM module, while obtaining location data from a GPS NEO 6M module. The system is powered by a Li-ion battery and includes a TP4056 module for battery charging and protection, with a rocker switch to control power to the microcontroller.
Cirkit Designer LogoOpen Project in Cirkit Designer
Cellular-Enabled IoT Device with Real-Time Clock and Power Management
Image of LRCM PHASE 2 BASIC: A project utilizing TL072 in a practical application
This circuit features a LilyGo-SIM7000G module for cellular communication and GPS functionality, interfaced with an RTC DS3231 for real-time clock capabilities. It includes voltage sensing through two voltage sensor modules, and uses an 8-channel opto-coupler for isolating different parts of the circuit. Power management is handled by a buck converter connected to a DC power source and batteries, with a fuse for protection and a rocker switch for on/off control. Additionally, there's an LED for indication purposes.
Cirkit Designer LogoOpen Project in Cirkit Designer
Arduino Nano 33 BLE Battery-Powered Display Interface
Image of senior design 1: A project utilizing TL072 in a practical application
This circuit features a Nano 33 BLE microcontroller interfaced with a TM1637 4-digit 7-segment display for information output, powered by a 3.7V battery managed by a TP4056 charging module. The microcontroller communicates with the display to present data, while the TP4056 ensures the battery is charged safely and provides power to the system.
Cirkit Designer LogoOpen Project in Cirkit Designer
Battery-Powered Health Monitoring System with Nucleo WB55RG and OLED Display
Image of Pulsefex: A project utilizing TL072 in a practical application
This circuit is a multi-sensor data acquisition system that uses a Nucleo WB55RG microcontroller to interface with a digital temperature sensor (TMP102), a pulse oximeter and heart-rate sensor (MAX30102), and a 0.96" OLED display via I2C. Additionally, it includes a Sim800l module for GSM communication, powered by a 3.7V LiPo battery.
Cirkit Designer LogoOpen Project in Cirkit Designer

Explore Projects Built with TL072

Use Cirkit Designer to design, explore, and prototype these projects online. Some projects support real-time simulation. Click "Open Project" to start designing instantly!
Image of women safety: A project utilizing TL072 in a practical application
Battery-Powered Emergency Alert System with NUCLEO-F072RB, SIM800L, and GPS NEO 6M
This circuit is an emergency alert system that uses a NUCLEO-F072RB microcontroller to send SMS alerts and make calls via a SIM800L GSM module, while obtaining location data from a GPS NEO 6M module. The system is powered by a Li-ion battery and includes a TP4056 module for battery charging and protection, with a rocker switch to control power to the microcontroller.
Cirkit Designer LogoOpen Project in Cirkit Designer
Image of LRCM PHASE 2 BASIC: A project utilizing TL072 in a practical application
Cellular-Enabled IoT Device with Real-Time Clock and Power Management
This circuit features a LilyGo-SIM7000G module for cellular communication and GPS functionality, interfaced with an RTC DS3231 for real-time clock capabilities. It includes voltage sensing through two voltage sensor modules, and uses an 8-channel opto-coupler for isolating different parts of the circuit. Power management is handled by a buck converter connected to a DC power source and batteries, with a fuse for protection and a rocker switch for on/off control. Additionally, there's an LED for indication purposes.
Cirkit Designer LogoOpen Project in Cirkit Designer
Image of senior design 1: A project utilizing TL072 in a practical application
Arduino Nano 33 BLE Battery-Powered Display Interface
This circuit features a Nano 33 BLE microcontroller interfaced with a TM1637 4-digit 7-segment display for information output, powered by a 3.7V battery managed by a TP4056 charging module. The microcontroller communicates with the display to present data, while the TP4056 ensures the battery is charged safely and provides power to the system.
Cirkit Designer LogoOpen Project in Cirkit Designer
Image of Pulsefex: A project utilizing TL072 in a practical application
Battery-Powered Health Monitoring System with Nucleo WB55RG and OLED Display
This circuit is a multi-sensor data acquisition system that uses a Nucleo WB55RG microcontroller to interface with a digital temperature sensor (TMP102), a pulse oximeter and heart-rate sensor (MAX30102), and a 0.96" OLED display via I2C. Additionally, it includes a Sim800l module for GSM communication, powered by a 3.7V LiPo battery.
Cirkit Designer LogoOpen Project in Cirkit Designer

Common Applications

  • Audio preamplifiers and mixers
  • Active filters and equalizers
  • Signal conditioning circuits
  • Oscillators and waveform generators
  • Instrumentation amplifiers

Technical Specifications

Key Specifications

Parameter Value
Supply Voltage (Vcc) ±3V to ±18V
Input Offset Voltage 3mV (typical)
Input Bias Current 65pA (typical)
Slew Rate 13V/µs (typical)
Gain Bandwidth Product 3MHz
Input Impedance 10⁸ Ω (typical)
Output Voltage Swing ±12V (at ±15V supply)
Noise Voltage (1kHz) 18nV/√Hz
Operating Temperature Range -40°C to +85°C
Package Types DIP-8, SOIC-8, TSSOP-8

Pin Configuration and Descriptions

The TL072 is typically available in an 8-pin package. Below is the pinout and description:

Pin Number Pin Name Description
1 Output A Output of the first operational amplifier
2 Inverting Input A Inverting input of the first op-amp
3 Non-Inverting Input A Non-inverting input of the first op-amp
4 V- (GND) Negative power supply or ground
5 Non-Inverting Input B Non-inverting input of the second op-amp
6 Inverting Input B Inverting input of the second op-amp
7 Output B Output of the second operational amplifier
8 V+ Positive power supply

Usage Instructions

Using the TL072 in a Circuit

  1. Power Supply: Connect the TL072 to a dual power supply (e.g., ±15V) for optimal performance. Ensure the supply voltage does not exceed the maximum rating of ±18V.
  2. Input Connections: Use the non-inverting and inverting inputs (pins 3 and 2 for op-amp A, pins 5 and 6 for op-amp B) to configure the desired circuit (e.g., amplifier, filter).
  3. Output: Connect the output pins (1 for op-amp A, 7 for op-amp B) to the load or next stage of the circuit.
  4. Bypass Capacitors: Place decoupling capacitors (e.g., 0.1µF ceramic and 10µF electrolytic) close to the power supply pins (V+ and V-) to reduce noise and improve stability.
  5. Feedback Network: Design the feedback network (resistors and capacitors) based on the desired gain and frequency response.

Example: TL072 with Arduino UNO

The TL072 can be used to amplify an analog signal before feeding it into the Arduino's ADC. Below is an example of a non-inverting amplifier circuit and Arduino code to read the amplified signal.

Circuit Diagram

  • Connect the signal source to the non-inverting input (pin 3).
  • Use a feedback resistor (Rf) and a resistor to ground (R1) to set the gain:
    Gain = 1 + (Rf / R1).
  • Connect the output (pin 1) to the Arduino's analog input (e.g., A0).

Arduino Code

// TL072 Amplifier Example with Arduino UNO
// Reads an amplified analog signal and prints the value to the Serial Monitor.

const int analogPin = A0; // Analog pin connected to TL072 output

void setup() {
  Serial.begin(9600); // Initialize serial communication at 9600 baud
}

void loop() {
  int sensorValue = analogRead(analogPin); // Read the analog input
  float voltage = sensorValue * (5.0 / 1023.0); // Convert to voltage
  Serial.print("Analog Value: ");
  Serial.print(sensorValue);
  Serial.print(" | Voltage: ");
  Serial.println(voltage, 3); // Print voltage with 3 decimal places
  delay(500); // Wait for 500ms before the next reading
}

Best Practices

  • Use precision resistors in the feedback network to minimize offset and noise.
  • Avoid exceeding the input voltage range to prevent distortion or damage.
  • Keep input and output traces short to reduce noise pickup.
  • Use proper grounding techniques to avoid ground loops.

Troubleshooting and FAQs

Common Issues and Solutions

  1. No Output Signal:

    • Check the power supply connections (V+ and V-).
    • Verify that the input signal is within the acceptable range.
    • Ensure the feedback network is correctly connected.
  2. Distorted Output:

    • Ensure the input signal amplitude does not exceed the op-amp's input range.
    • Check for proper decoupling capacitors on the power supply lines.
    • Verify that the load impedance is not too low for the op-amp to drive.
  3. High Noise in Output:

    • Use shielded cables for input signals.
    • Add bypass capacitors close to the power supply pins.
    • Ensure proper grounding and avoid long input/output traces.
  4. Overheating:

    • Verify that the supply voltage is within the specified range.
    • Check for excessive current draw due to incorrect circuit design.

FAQs

Q1: Can the TL072 operate with a single power supply?
A1: Yes, the TL072 can operate with a single supply (e.g., 0V and +12V), but the input and output signals must be biased appropriately to stay within the op-amp's operating range.

Q2: What is the maximum gain I can achieve with the TL072?
A2: Theoretically, the gain can be very high, but practical limitations such as bandwidth, stability, and noise must be considered. For high gains, ensure proper compensation and feedback design.

Q3: Is the TL072 suitable for high-frequency applications?
A3: The TL072 has a gain bandwidth product of 3MHz, making it suitable for low to moderate frequency applications. For higher frequencies, consider op-amps with a higher bandwidth.

Q4: Can I use the TL072 for audio applications?
A4: Yes, the TL072 is widely used in audio circuits due to its low noise and distortion characteristics.
