The DFR1026 is a digital temperature and humidity sensor manufactured by DFRobot. It is designed to provide accurate and reliable environmental readings, making it an essential component for applications requiring precise monitoring of temperature and humidity. Its compact design and digital output make it ideal for integration into weather stations, HVAC systems, IoT devices, and other environmental monitoring systems.
Explore Projects Built with DFR1026
Use Cirkit Designer to design, explore, and prototype these projects online. Some projects support real-time simulation. Click "Open Project" to start designing instantly!
This circuit is a battery-powered system featuring an ESP32 microcontroller that controls an OLED display, a motor driver for two hobby motors, an ultrasonic sensor for distance measurement, and a DFPlayer Mini for audio output through a loudspeaker. The TP4056 module manages battery charging, and a step-up boost converter provides a stable 5V supply to the components.
This circuit features a microcontroller (STM32F103C8T6) interfaced with a SIM900A GSM module, an HC-SR04 ultrasonic sensor, a water level sensor, and a LoRa Ra-02 SX1278 module for long-range communication. The STM32F103C8T6 is configured to communicate with the GSM module and LoRa module via serial connections, and it reads data from the ultrasonic and water level sensors. An FTDI Programmer is connected for programming and serial communication with the microcontroller.
This is a multi-functional sensor system controlled by an Arduino Mega 2560, designed to read biometric data from a pulse oximeter and an infrared thermometer, authenticate using a fingerprint scanner, display information on an OLED screen, and transmit data wirelessly via an ESP8266 module. User inputs can be received through two pushbuttons, and the system's power distribution is managed through common ground and voltage supply nets.
This circuit is an emergency alert system that uses a NUCLEO-F072RB microcontroller to send SMS alerts and make calls via a SIM800L GSM module, while obtaining location data from a GPS NEO 6M module. The system is powered by a Li-ion battery and includes a TP4056 module for battery charging and protection, with a rocker switch to control power to the microcontroller.
Weather stations for real-time environmental data collection
HVAC systems for temperature and humidity regulation
IoT devices for smart home automation
Agricultural monitoring systems
Industrial environments requiring climate control
Technical Specifications
The DFR1026 sensor is engineered for high performance and ease of use. Below are its key technical specifications:
Parameter
Value
Manufacturer
DFRobot
Part ID
DFR1026
Measurement Range
Temperature: -40°C to 80°C
Humidity: 0% to 100% RH
Accuracy
Temperature: ±0.5°C
Humidity: ±2% RH
Operating Voltage
3.3V to 5.5V
Communication Protocol
Digital (I2C)
Power Consumption
<2 mA (active mode)
Response Time
<2 seconds
Dimensions
15mm x 10mm x 5mm
Pin Configuration
The DFR1026 features a 4-pin interface for easy connection to microcontrollers. Below is the pinout description:
Pin
Name
Description
1
VCC
Power supply input (3.3V to 5.5V)
2
GND
Ground connection
3
SDA
Serial Data Line for I2C communication
4
SCL
Serial Clock Line for I2C communication
Usage Instructions
Connecting the DFR1026 to a Circuit
Power Supply: Connect the VCC pin to a 3.3V or 5V power source and the GND pin to the ground.
I2C Communication: Connect the SDA and SCL pins to the corresponding I2C pins on your microcontroller. For an Arduino UNO, connect:
SDA to A4
SCL to A5
Pull-Up Resistors: Ensure that the I2C lines (SDA and SCL) have pull-up resistors (typically 4.7kΩ) if not already included in your circuit.
Sample Code for Arduino UNO
Below is an example of how to use the DFR1026 with an Arduino UNO to read temperature and humidity data:
#include <Wire.h>
// Define the I2C address of the DFR1026 sensor
#define DFR1026_ADDRESS 0x40
void setup() {
Wire.begin(); // Initialize I2C communication
Serial.begin(9600); // Start serial communication for debugging
Serial.println("DFR1026 Sensor Initialization...");
}
void loop() {
Wire.beginTransmission(DFR1026_ADDRESS); // Start communication with sensor
Wire.write(0x00); // Command to request data (specific to DFR1026 protocol)
Wire.endTransmission();
delay(50); // Wait for sensor to process the request
Wire.requestFrom(DFR1026_ADDRESS, 4); // Request 4 bytes of data
if (Wire.available() == 4) {
uint16_t rawTemp = (Wire.read() << 8) | Wire.read(); // Read temperature
uint16_t rawHumidity = (Wire.read() << 8) | Wire.read(); // Read humidity
// Convert raw data to human-readable values
float temperature = (rawTemp / 65536.0) * 165.0 - 40.0; // Convert to °C
float humidity = (rawHumidity / 65536.0) * 100.0; // Convert to %RH
// Print the results
Serial.print("Temperature: ");
Serial.print(temperature);
Serial.println(" °C");
Serial.print("Humidity: ");
Serial.print(humidity);
Serial.println(" %RH");
} else {
Serial.println("Error: No data received from DFR1026 sensor.");
}
delay(2000); // Wait 2 seconds before the next reading
}
Best Practices
Use decoupling capacitors (e.g., 0.1µF) near the VCC pin to stabilize the power supply.
Avoid placing the sensor in direct sunlight or near heat sources for accurate readings.
Ensure proper ventilation around the sensor for optimal performance.
Use shielded cables for long I2C connections to reduce noise interference.
Troubleshooting and FAQs
Common Issues and Solutions
No Data Received from the Sensor
Cause: Incorrect I2C address or wiring.
Solution: Verify the I2C address (default is 0x40) and check all connections.
Inaccurate Readings
Cause: Sensor exposed to extreme conditions or interference.
Solution: Ensure the sensor is within its operating range and away from interference sources.
I2C Communication Errors
Cause: Missing pull-up resistors on SDA and SCL lines.
Solution: Add 4.7kΩ pull-up resistors to the I2C lines.
Slow Response Time
Cause: Insufficient delay between readings.
Solution: Add a delay of at least 2 seconds between consecutive readings.
FAQs
Q: Can the DFR1026 operate at 3.3V?
A: Yes, the DFR1026 supports an operating voltage range of 3.3V to 5.5V.
Q: Is the sensor waterproof?
A: No, the DFR1026 is not waterproof. Avoid exposing it to water or high humidity for extended periods.
Q: Can I use the DFR1026 with a Raspberry Pi?
A: Yes, the DFR1026 can be used with a Raspberry Pi via its I2C interface. Ensure proper configuration of the I2C pins.
Q: What is the maximum cable length for I2C communication?
A: The maximum cable length depends on the pull-up resistor values and the operating frequency. For standard 4.7kΩ resistors, keep the cable length under 1 meter to avoid signal degradation.
By following this documentation, you can effectively integrate the DFR1026 sensor into your projects for accurate temperature and humidity monitoring.
