Design with Lifepo4 Baterai 12.8V 200 AH in Cirkit DesignerThe LiFePO4 Battery 12.8V 200Ah (Manufacturer: ESP32, Part ID: WROOM 32D) is a high-capacity lithium iron phosphate battery designed for applications requiring reliable, long-lasting, and safe energy storage. With a nominal voltage of 12.8V and a capacity of 200Ah, this battery is ideal for use in renewable energy systems, electric vehicles, backup power supplies, and off-grid setups. Its superior thermal stability and long cycle life make it a safer and more durable alternative to traditional lithium-ion batteries.
This circuit is a solar power system that charges a 12V 200Ah battery using a solar panel through a solar charge controller. The system also includes a DC-DC buck converter to step down the voltage from the battery for powering a load.
Open Project in Cirkit Designer
This circuit is designed to charge a 12V 200Ah battery using power from a solar panel, with a solar charge controller regulating the charging process. An AC source is rectified to DC using a bridge rectifier, which then feeds into a step-up boost power converter to produce a higher voltage output, possibly for an external AC load. Additionally, a DC-DC converter is used to step down the voltage to 5V for use with a 5V connector, likely for low-power devices or logic circuits.
Open Project in Cirkit Designer
This circuit is a solar power system that charges two 12V 200Ah batteries using a solar panel through a solar charge controller. The stored energy in the batteries is then converted to 220V AC power by a power inverter, which can be used to power AC devices.
Open Project in Cirkit Designer
This circuit is a solar power management system that includes a solar panel, an MPPT solar charge controller, a 12V 200Ah battery, and various voltage converters. The system is designed to harness solar energy, store it in a battery, and provide regulated power outputs at different voltages for various loads.
Open Project in Cirkit Designer| Parameter | Value |
|---|---|
| Nominal Voltage | 12.8V |
| Capacity | 200Ah |
| Energy | 2560Wh |
| Chemistry | Lithium Iron Phosphate (LiFePO4) |
| Cycle Life | >4000 cycles (at 80% DOD) |
| Maximum Charge Voltage | 14.6V |
| Discharge Cut-off Voltage | 10.0V |
| Continuous Discharge Current | 100A |
| Peak Discharge Current | 200A (for 10 seconds) |
| Operating Temperature | -20°C to 60°C (Discharge) |
| Weight | ~25kg |
| Dimensions | 330mm x 173mm x 220mm |
The LiFePO4 battery does not have traditional pins but includes terminals for connection. Below is a description of the terminals:
| Terminal | Description |
|---|---|
| Positive (+) | Connects to the positive side of the circuit or load. |
| Negative (-) | Connects to the negative side of the circuit or load. |
Connection:
Charging:
Discharging:
Protection:
To power an Arduino UNO using the LiFePO4 battery, you can use a DC-DC step-down converter to regulate the voltage to 5V. Below is an example circuit and code:
// Example Arduino Code: Reading Battery Voltage
// This code reads the battery voltage using an analog pin and displays it
// on the serial monitor. Ensure a voltage divider is used to step down
// the battery voltage to a safe range for the Arduino's analog input.
const int analogPin = A0; // Analog pin connected to the voltage divider
const float voltageDividerRatio = 5.7; // Adjust based on your resistor values
const float referenceVoltage = 5.0; // Arduino reference voltage (5V for UNO)
void setup() {
Serial.begin(9600); // Initialize serial communication
}
void loop() {
int sensorValue = analogRead(analogPin); // Read analog value
float batteryVoltage = (sensorValue * referenceVoltage / 1023.0) * voltageDividerRatio;
// Print the battery voltage to the serial monitor
Serial.print("Battery Voltage: ");
Serial.print(batteryVoltage);
Serial.println(" V");
delay(1000); // Wait for 1 second before the next reading
}
| Issue | Possible Cause | Solution |
|---|---|---|
| Battery not charging | Charger not compatible or faulty | Use a LiFePO4-compatible charger. |
| Battery discharges too quickly | Load exceeds battery capacity | Reduce load or check for short circuits. |
| Battery overheating | Overcharging or excessive discharge current | Ensure proper ventilation and use a BMS. |
| Voltage drops below 10.0V | Over-discharge | Recharge immediately to prevent damage. |
Can I connect this battery in series or parallel?
What is the expected lifespan of this battery?
Is this battery safe for indoor use?
Can I use this battery to power an inverter?
This documentation provides a comprehensive guide to using the LiFePO4 Battery 12.8V 200Ah safely and effectively. Always follow the manufacturer's guidelines for optimal performance and safety.
