Introduction

The Arduino Nano is a compact microcontroller board based on the ATmega328P, designed for easy integration into a wide range of electronic projects. It features digital and analog input/output pins, USB connectivity for programming, and a small form factor, making it ideal for prototyping and embedding into space-constrained designs. The Nano is widely used in applications such as robotics, IoT devices, sensor interfacing, and educational projects due to its versatility and ease of use.

Explore Projects Built with Arduino Nano

Use Cirkit Designer to design, explore, and prototype these projects online. Some projects support real-time simulation. Click "Open Project" to start designing instantly!
Arduino Nano and OLED Display for Real-Time Data Visualization
Image of OLED Display: A project utilizing Arduino Nano in a practical application
This circuit consists of an Arduino Nano microcontroller connected to a 0.96" OLED display. The Arduino Nano provides power to the OLED display and communicates with it using the I2C protocol via the A4 (SDA) and A5 (SCK) pins.
Cirkit Designer LogoOpen Project in Cirkit Designer
Arduino Nano-Based Portable GSM-GPS Navigator with Compass and Stepper Motor Control
Image of Compass: A project utilizing Arduino Nano in a practical application
This circuit features an Arduino Nano microcontroller coordinating communication, navigation, and motion control functions. It includes modules for GSM, GPS, and digital compass capabilities, as well as a stepper motor for precise movement, all powered by a LiPo battery with voltage regulation.
Cirkit Designer LogoOpen Project in Cirkit Designer
Arduino Nano Basic Setup for Embedded Projects
Image of yt: A project utilizing Arduino Nano in a practical application
This circuit consists of an Arduino Nano microcontroller with no external components connected. The provided code is a basic template with empty setup and loop functions, indicating that the circuit is likely intended for initial testing or development purposes.
Cirkit Designer LogoOpen Project in Cirkit Designer
Arduino-Based Bluetooth-Controlled Servo System with Flex Sensors and MPU-6050
Image of Copy of Robot + Glove: A project utilizing Arduino Nano in a practical application
This circuit consists of an Arduino UNO and an Arduino Nano, which communicate via Bluetooth modules. The Arduino Nano reads data from two flex sensors and an MPU-6050 accelerometer, sending the data to the Arduino UNO. The Arduino UNO controls three micro servos through a PCA9685 PWM driver, moving them back and forth.
Cirkit Designer LogoOpen Project in Cirkit Designer

Explore Projects Built with Arduino Nano

Use Cirkit Designer to design, explore, and prototype these projects online. Some projects support real-time simulation. Click "Open Project" to start designing instantly!
Image of OLED Display: A project utilizing Arduino Nano in a practical application
Arduino Nano and OLED Display for Real-Time Data Visualization
This circuit consists of an Arduino Nano microcontroller connected to a 0.96" OLED display. The Arduino Nano provides power to the OLED display and communicates with it using the I2C protocol via the A4 (SDA) and A5 (SCK) pins.
Cirkit Designer LogoOpen Project in Cirkit Designer
Image of Compass: A project utilizing Arduino Nano in a practical application
Arduino Nano-Based Portable GSM-GPS Navigator with Compass and Stepper Motor Control
This circuit features an Arduino Nano microcontroller coordinating communication, navigation, and motion control functions. It includes modules for GSM, GPS, and digital compass capabilities, as well as a stepper motor for precise movement, all powered by a LiPo battery with voltage regulation.
Cirkit Designer LogoOpen Project in Cirkit Designer
Image of yt: A project utilizing Arduino Nano in a practical application
Arduino Nano Basic Setup for Embedded Projects
This circuit consists of an Arduino Nano microcontroller with no external components connected. The provided code is a basic template with empty setup and loop functions, indicating that the circuit is likely intended for initial testing or development purposes.
Cirkit Designer LogoOpen Project in Cirkit Designer
Image of Copy of Robot + Glove: A project utilizing Arduino Nano in a practical application
Arduino-Based Bluetooth-Controlled Servo System with Flex Sensors and MPU-6050
This circuit consists of an Arduino UNO and an Arduino Nano, which communicate via Bluetooth modules. The Arduino Nano reads data from two flex sensors and an MPU-6050 accelerometer, sending the data to the Arduino UNO. The Arduino UNO controls three micro servos through a PCA9685 PWM driver, moving them back and forth.
Cirkit Designer LogoOpen Project in Cirkit Designer

Technical Specifications

  • Microcontroller: ATmega328P
  • Operating Voltage: 5V
  • Input Voltage (recommended): 7-12V
  • Input Voltage (limit): 6-20V
  • Digital I/O Pins: 14 (6 of which provide PWM output)
  • Analog Input Pins: 8
  • DC Current per I/O Pin: 40 mA
  • Flash Memory: 32 KB (2 KB used by bootloader)
  • SRAM: 2 KB
  • EEPROM: 1 KB
  • Clock Speed: 16 MHz
  • Dimensions: 18 x 45 mm
  • Weight: 7 g

Pin Configuration and Descriptions

The Arduino Nano has a total of 30 pins. Below is a detailed description of the pin configuration:

Pin Type Description
VIN Power Input Input voltage to the board when using an external power source (7-12V recommended).
GND Ground Ground pins (multiple GND pins available).
5V Power Output Regulated 5V output from the board.
3.3V Power Output Regulated 3.3V output (maximum current: 50 mA).
A0-A7 Analog Input Analog input pins (10-bit resolution).
D0-D13 Digital I/O Digital input/output pins.
PWM PWM Output Pins D3, D5, D6, D9, D10, and D11 support PWM output.
TX (D1) UART Transmit Transmit pin for serial communication.
RX (D0) UART Receive Receive pin for serial communication.
RST Reset Resets the microcontroller.
ICSP Programming In-Circuit Serial Programming header for flashing the microcontroller.

Usage Instructions

How to Use the Arduino Nano in a Circuit

  1. Powering the Board:

    • Connect the Arduino Nano to your computer via a USB Mini-B cable for programming and power.
    • Alternatively, supply power through the VIN pin (7-12V recommended) or the 5V pin (regulated 5V).
  2. Programming the Board:

    • Install the Arduino IDE from the official Arduino website.
    • Select "Arduino Nano" as the board type in the Tools menu.
    • Choose the correct processor (ATmega328P or ATmega328P (Old Bootloader)) and the appropriate COM port.
    • Write your code in the IDE and upload it to the board.
  3. Connecting Components:

    • Use the digital pins (D0-D13) for digital input/output operations.
    • Use the analog pins (A0-A7) for reading analog signals (e.g., from sensors).
    • Connect external components like LEDs, motors, or sensors to the appropriate pins, ensuring current and voltage limits are not exceeded.

Example Code: Blinking an LED

The following example demonstrates how to blink an LED connected to pin D13:

// This code blinks an LED connected to pin D13 on the Arduino Nano.
// The LED will turn on for 1 second and off for 1 second in a loop.

void setup() {
  pinMode(13, OUTPUT); // Set pin D13 as an output pin
}

void loop() {
  digitalWrite(13, HIGH); // Turn the LED on
  delay(1000);            // Wait for 1 second
  digitalWrite(13, LOW);  // Turn the LED off
  delay(1000);            // Wait for 1 second
}

Important Considerations and Best Practices

  • Avoid drawing more than 40 mA from any single I/O pin to prevent damage to the microcontroller.
  • Use a resistor (e.g., 220Ω) in series with LEDs to limit current and protect the LED and pin.
  • When using external power, ensure the voltage is within the recommended range (7-12V for VIN).
  • For precise analog readings, avoid using the 3.3V pin to power sensors, as it has limited current capacity.

Troubleshooting and FAQs

Common Issues and Solutions

  1. Problem: The Arduino Nano is not recognized by the computer.

    • Solution: Ensure the correct USB driver is installed. For older Nano boards, install the CH340 driver if required.
  2. Problem: The code does not upload to the board.

    • Solution: Check that the correct board type and processor are selected in the Arduino IDE. If using an older Nano, select "ATmega328P (Old Bootloader)."
  3. Problem: The board is not powering on.

    • Solution: Verify the power source. If using USB, ensure the cable is functional. If using VIN, check the input voltage.
  4. Problem: Analog readings are unstable.

    • Solution: Use a decoupling capacitor (e.g., 0.1 µF) between the sensor's power and ground pins to reduce noise.

FAQs

  • Q: Can I power the Arduino Nano with a battery?

    • A: Yes, you can use a battery with a voltage between 7-12V connected to the VIN pin.
  • Q: What is the difference between the Nano and the Uno?

    • A: The Nano is smaller and more compact, making it suitable for space-constrained projects. It also uses a Mini-B USB connector instead of a Type-B connector.
  • Q: Can I use the Nano for wireless communication?

    • A: Yes, you can connect wireless modules like Bluetooth (HC-05) or Wi-Fi (ESP8266) to the Nano via its UART or I2C pins.

By following this documentation, you can effectively integrate the Arduino Nano into your projects and troubleshoot common issues with ease.
