Introduction

The MT4W-DA-4N FIX is a terminal block designed for connecting multiple wires in a secure and organized manner. It features four connection points, making it ideal for applications requiring multiple wire terminations. This component is widely used in electrical systems to simplify wiring, ensure reliable connections, and facilitate easy maintenance. Its robust design and ease of use make it a popular choice in industrial, commercial, and residential electrical installations.
