How to Use Power supply 230v/12v/5v: Examples, Pinouts, and Specs

The Power Supply 230V/12V/5V is a versatile device designed to convert standard mains electricity (230V AC) into lower, regulated DC voltages of 12V and 5V. This component is essential for powering a wide range of electronic devices and circuits, including microcontrollers, sensors, and other low-voltage components. It ensures stable and reliable power delivery, making it a critical component in both hobbyist and professional electronic projects.

• Powering microcontroller boards (e.g., Arduino, Raspberry Pi)
• Supplying power to sensors, relays, and actuators
• Use in home automation systems
• Powering LED strips and other low-voltage lighting
• General-purpose DC power supply for prototyping and testing circuits

The following table outlines the key technical details of the Power Supply 230V/12V/5V:

The power supply typically has the following input and output connections:

1. Connect the Input:

   • Connect the AC-L and AC-N terminals to the live and neutral wires of the 230V AC mains supply. Ensure proper insulation and safety precautions when handling mains electricity.
   • Use a fuse or circuit breaker for added protection.

2. Connect the Output:

   • Use the +12V and +5V terminals to power your devices or circuits. Ensure the total current draw does not exceed the rated maximum output current for each voltage.

3. Grounding:

   • Connect the GND terminal to the ground of your circuit to complete the power loop.

4. Verify Connections:

   • Double-check all connections before powering on the device to avoid damage to the power supply or connected components.

• Safety First: Always handle the 230V AC input with care. Use insulated tools and avoid working on the power supply while it is connected to mains power.
• Load Requirements: Ensure the connected devices do not exceed the maximum current ratings for the 12V and 5V outputs.
• Ventilation: Place the power supply in a well-ventilated area to prevent overheating.
• Polarity: Verify the polarity of the output connections to avoid damaging your devices.
• Testing: Use a multimeter to confirm the output voltages before connecting sensitive electronics.

The 5V output of the power supply can be used to power an Arduino UNO. Below is an example of how to connect and use it:

1. Connect the +5V terminal of the power supply to the 5V pin on the Arduino UNO.
2. Connect the GND terminal of the power supply to the GND pin on the Arduino UNO.

// Example code to blink an LED using the Arduino UNO powered by the 5V output
// of the Power Supply 230V/12V/5V. Ensure proper connections before running.

const int ledPin = 13; // Pin connected to the onboard LED

void setup() {
  pinMode(ledPin, OUTPUT); // Set the LED pin as an output
}

void loop() {
  digitalWrite(ledPin, HIGH); // Turn the LED on
  delay(1000);                // Wait for 1 second
  digitalWrite(ledPin, LOW);  // Turn the LED off
  delay(1000);                // Wait for 1 second
}

1. No Output Voltage:

   • Cause: Incorrect input connections or no mains power.
   • Solution: Verify the AC-L and AC-N connections and ensure the mains power is on.

2. Overheating:

   • Cause: Exceeding the maximum current rating or poor ventilation.
   • Solution: Reduce the load or improve ventilation around the power supply.

3. Voltage Fluctuations:

   • Cause: Unstable mains supply or excessive load.
   • Solution: Use a voltage stabilizer for the mains input or reduce the load.

4. Short Circuit Protection Triggered:

   • Cause: A short circuit in the connected circuit.
   • Solution: Inspect and fix the short circuit before reconnecting the power supply.

Q1: Can I use this power supply to charge a 12V battery?
A1: No, this power supply is not designed for battery charging as it lacks the necessary current regulation and charging profiles.

Q2: Is it safe to use this power supply outdoors?
A2: No, this power supply is not weatherproof. Use it only in dry, indoor environments.

Q3: Can I power both 12V and 5V devices simultaneously?
A3: Yes, as long as the total current draw does not exceed the rated maximum for each output.

Q4: What happens if I connect a load that exceeds the current rating?
A4: The power supply's overload protection will activate, shutting down the output to prevent damage.

By following this documentation, you can safely and effectively use the Power Supply 230V/12V/5V in your electronic projects.
